Description
Surron Light Bee X: Electric Dirt Bike
Unleash the beast with the Surron Light Bee X electric dirt bike, a perfect blend of dirt bike torque and the agility of a downhill bicycle. Featuring a robust 6kW electric motor, 75km of cruising range, and a top speed of 75km/h, the Light Bee X offers high performance all packed into a lightweight 56kg package.
Its sleek, edgy design, zero emissions, and noise-free operation have quickly made the Light Bee X a global sensation. Since its launch in 2016, the Light Bee X has earned a formidable reputation, competing fiercely against traditional petrol bikes. However, this off-road powerhouse is designed for private property use only and is not street-legal.
HIGH-PERFORMANCE 6000W MOTOR
At the heart of the Light Bee X lies a high-performance Permanent Magnet Brushless DC Motor designed by Surron. Delivering immense power and efficiency, this motor includes an electronic braking function for enhanced control and safety. With an IP55 rating and the ability to withstand temperatures up to 180°C, it guarantees reliability even under the most demanding conditions. The powertrain features a 60V lithium-ion battery, a precise FOC sine wave controller, and a PMSM motor capable of a maximum rotational speed of 5,400rpm, ensuring exceptional performance.
FOV SINE WAVE CONTROLLER
Surron’s meticulously developed multi-curve compound algorithm optimises the riding experience by continuously monitoring handlebar input, motor torque, and current intensity. This advanced system, paired with the Light Bee X, adapts in real-time to your riding habits, providing a seamless and personalised ride.
IMPRESSIVE POWER-TO-WEIGHT RATIO
The Surron Light Bee X electric dirt bike’s central motor placement and high power-to-weight ratio propel it to speeds up to 75 km/h and enable it to climb hills as steep as 45 degrees. Switch to Sport mode to unlock the bike’s full potential and experience its thrilling capabilities.
EXCLUSIVE SUSPENSION
Equipped with a fully adjustable (compression & rebound damping) front fork with 200mm of travel, the Light Bee X suspension has been optimised through extensive testing on cross-country tracks and trails. Adjust the settings to match your riding style for ideal bump absorption and tyre grip, making it a top contender among electric dirt bikes.
HIGH-PRESSURE FORGED FRAME
Experience unmatched strength and agility with the Surron Light Bee X. Designed for durability and sporty ergonomics, its high-pressure forged frame, built with 6000 tons of precision, strikes the perfect balance between rigidity and flexibility. This ensures superior performance and handling, offering an exhilarating ride with every turn.
IMPRESSIVE POWER-TO-WEIGHT RATIO
The Light Bee X’s central motor placement and high power-to-weight ratio propel it to speeds of up to 75 km/h and enable it to climb hills as steep as 45 degrees. Switch to Sport mode to unlock the bike’s full potential and experience its thrilling capabilities.
OFF-ROAD BRAKING SYSTEM
The Light Bee X features dual power output modes. In ‘Sports’ mode, it delivers up to 6kW of power and 250Nm of torque, making jumps and wheelies effortless. ‘Eco’ mode provides a softened power delivery, perfect for building confidence and conserving energy during longer rides on this electric dirt bike.
INTEGRATED BRAKE CALIPER
The compact structure of the aluminium alloy forged frame lowers the centre of gravity, offering unmatched precision handling characteristics to riders of all abilities.
HIGH-PERFORMANCE REMOVABLE LITHIUM BATTERY
The Surron Light Bee X is powered by a 60V40Ah battery pack featuring a safe and efficient management module. Multiple temperature sensors and SCM 485 communication protocol ensure high power load capacity and long service life. Weighing only 11.6kg, the battery can be removed in under 10 seconds for easy swapping. Enjoy up to 75 km of cruising range and 3-5 hours of continuous riding, ideal for extended off-road adventures on this cutting-edge electric dirt bike.
NTERSECT TR
Surron’s self-developed Intersect TR multi-link rod rear suspension system integrates with the bike’s structure and adjusts to the characteristics of electric off-road riding. This ensures the rear tyre maintains optimal traction and drive, enhancing the overall off-road experience with the Light Bee X.
Please Note: The images shown are for display use only and may not accurately depict the actual product. Differences in color, design, or features may occur.
(EL0154-p , SUR.LBEEX.BAS.BLK, SUR.LBEEX.BAS.BLU, SUR.LBEEX.BAS.PUR, SUR.LBEEX.BAS.SIL )
Features
Ultra Lightweight Frame
The Light Bee's 7.8 kg frame is constructed of aviation-grade aluminum alloy via a fully automatic welding process that ensures consistency in production.
High Performance Brakes
The braking system features opposed, four-piston hydraulic calipers with metallic brake pads and 203 mm discs for safe and reliable stopping power.
Sporty Performance
In SPORTS mode, the Light Bee X puts out 6 kW of power and 250 Nm of torque. That's more than enough for tackling jumps and climbing hills!
Specifications
|
DRIVE |
|
|---|---|
|
Motor |
Permanent Magnet Synchronous (PMSM) |
|
Controller |
FOC Sinewave Controller |
|
Rated Power |
3000w |
|
Max. Power: |
6000w |
|
Max. Torque: |
250Nm |
|
Transmission: |
Belt and Chain – 1:7.6 ratio |
|
Throttle: |
Ride-by-wire |
|
Top Speed: |
75km/h |
|
Max. Range: |
75km @ 40km/h |
|
RIDE MODES |
|
|---|---|
|
ECO: |
The ultimate mode for energy-conserving exploration |
|
SPORTS: |
Maximum torque, acceleration and speed |
|
BATTERY |
|
|---|---|
|
Battery Type: |
60V/ 2,400Wh, 40Ah Lithium-ion (Removable) |
|
Charge Time: |
4 Hours |
|
Display: |
LCD Multi-Function |
|
SUSPENSION |
|
|---|---|
|
Front Suspension: |
KKE Inverted Fork, fully adjustable with 200mm travel |
|
Rear Suspension: |
KKE single rear shock with 210mm wheel travel |
|
BRAKES |
|
|---|---|
|
Front/Rear: |
Bilateral 4-Piston Hydraulic, 203mm Vented Disc |
|
WHEELS & TYRES |
|
|---|---|
|
Front Wheel: |
70/100-19, CST off-road tyre |
|
Rear Wheel: |
70/100-19, CST off-road tyre |
|
DIMENSIONS |
|
|---|---|
|
L x W x H: |
1,885mm x 780mm x 1,050mm |
|
Wet Weight: |
56Kg |
|
Carrying Capacity: |
100Kg |
|
Wheelbase: |
1,255mm |
|
Seat Height: |
830mm |
|
Ground Clearance: |
270mm |
|
INCLUSIONS |
|
|---|---|
|
Rider Aids: |
Surron Energy Regenerative System |
|
In the box: |
10A Fast Charger, Front Plate, 2 Keys & an Owner’s Manual |
| Brand | Sur-Ron |
| Category | |
| SKU | EL0154-p |
Surron Light Bee X Electric Dirt Bike Black
SKU code: SUR.LBEEX.BAS.BLK
